SLS 50755



Construction :

  • Inner conductor Plain copper 7 x 0.40 mm
    Dielectric Foam PE Φ4.95 ± 0.10 mm
    Outer conductor (shield 1) Aluminium + polyester + Aluminium tape
    Shield coverage   100%
    Outer conductor (shield 2) Tinned copper 96 x 0.15 mm
    Shield coverage   71%
    Sheath Blue PVC Φ7.00 ± 0.10 mm
  •
  •

Electrical & Mechanical Characteristics :

  • Impedance 75±5 Ohm
    Nominal capacitance 53 pF/m
    Velocity of propagation 84%
    Insulation resistance >5000 Mohm.Km
    Inner conductor resistance 20.5 Ohm/Km
    Outer conductor resistance 13.5 Ohm/Km
    Operating temperature range -25 °C - +80 °C
    Copper weight 24.6 Kg/Km
    Cable weight (approx.) 56.25 Kg/Km
    Screening effectiveness >85 dB

Attenuation :

  • Frequency(MHz) Attenuation (dB/100 m) Attenuation (dB/100 ft)
    50 4.4 1.34
    230 9.5 2.90
    470 13.7 4.18
    860 19.2 5.85
    1000 21.0 6.40
    1350 24.7 7.53
    1500 26.6 8.11
    1750 28.7 8.75
    2150 32.4 9.88
    2400 34.7 10.58

Return Loss :

  • 30-470 MHz >30dB
    470-860 MHz >26dB
    860-2400 MHz >22dB
